Gamma Spectrometer for PRA, Theremino, Impulse and Becqmoni MCA (with sound card sampling)

The latest Gammaspectacular, it's improved design makes it the best Theremino spectrometer, it draws on all the experience and feedback received from over 2000 customers. The GS-PRO-5 comes in a high quality machined aluminium enclosure and measures 100 x 100 x 35 mm. This version has many improvements in the circuit, improving the functionality.

The GS-PRO-V5 runs on free software and works with any PC or Mac and works with any brand of PMT based scintillation detector for spectrometry.

Inbuilt Audio Codec (ADC)

Built in audio codec (ADC), eliminating the need for external audio connection to the PC sound card, this enhancement has significantly improved the signal to noise ratio and ease of use.

2000V Bias SHV Connector

SHV connector for the high voltage bias and BNC connector for the optional signal input, making it compatible with most brands of detectors.

Adjustable Volume and Pulse Shape

Control over preamplifier pulse gain and shape via separate trimmer potentiometers accessible without opening the enclosure, very convenient for optimisation of the dynamic range

Compact Enclosure

New custom designed enclosure allowing for future upgrades and modifications

Multifunction Audio Jack

The multi function audio jack can be assigned as an input or an output making it easy to connect analogue measuring instruments. The audio jack right channel functions as an input, making it possible to connect two units together with a stereo crossover cable for coincidence counting.

USB Type-C Connector

The GS-PRO-V is the first model to come with USB type-C connector. (Note the protocol remains USB 2.0)

Included

Brochure

Download Brochure

Made in Australia
